Advantage
● Film-type single seat valve can bear higher pressure ≤ 30, shorter height, stainless steel
Technical Specifications
Size: DN10-DN150, 1/2"-6"
Material: 304/1.4301, 316L/1.4404, ASME BPE 316L 1.4435 NB2 Fe≤0.5%
Standard: DIN SMS ISO IDF RJT BS4825 ASME BPE 3A DIN11864 DIN11853
Connection: thread, clamp, flange, weld
Drive mode: Film-type pneumatic actuator
Pressure: vacuum to 10bar (1.0Mpa)
Temperature: max 140℃
Seal material: EPDM SILICON FKM FFKM HNBR FVMQ NBR
Certificattion: FDA177.2600; Glass II USP Glass VI Chapter 88; GB4806.11; EG VO/1935-2004; PED/97/23/EC
