Manual or pneumatic operation, specifically for sanitary and aseptic processes in the pharmaceutical industry. This valve is ideal for fluid control and on/off tasks. The diaphragm provides a body seal and a seat seal. There is no path to the outside environment, so the diaphragm valve is suitable for aseptic processes. When the valve is closed, the pressure pad supporting the diaphragm moves toward the sealing surface on the valve body. As the
pressure plate moves, the diaphragm bends and is forced to the seat area in the center of the valve body, thus closing the fluid path to the valve body. The relationship between the valve body and the pressure plate prevents the compression of the diaphragm. The valve can be operated manually or pneumatically, or it can be controlled by a controller and solenoid valve.
◎Specifications: 1"-4", DN25-DN100
◎ Pressure: 10bar (145 PSI)
◎Material: ASTM 316L, 1.4404, 1.4435 NB2 Fe<0.5%
◎Temperature: -20°C +150°C (EPDM)-4°F+302°F (+140°C (SIP, 30) 284°F)
◎Connection: clamp, welding, thread, 3A BPE DIN SMS IDF ISO
◎ valve body structure: straight through, three-way, U-shaped three-way, tank bottom valve, multi-channel diaphragm valve
◎ Diaphragm material: EPDM + PTFE (double layer) / EPDM / Silicon / FPM (Vitong)
◎ Certification: 3A-54-02/1580, PED 97/23 EC, FDA177.2600

Pneumatic Diaphragm Valve
●Diaphragm valves, manually or pneumatically operated, are specifically designed for hygienic and aseptic processes in the pharmaceutical industries.
●The valve is excellent for flow control as well as for open/close duties.
●The diaphragm provides body seal as well as seat seal. There are no paths to outside environment so it is suitable for aseptic processes.
● When valve is closed, a pressure pad which supports diaphragm to move towards sealing face on body. When pressure plate moves, diaphragm flexes and is forced down onto seat area in the centre of body, thus it closed off flow path through body.
● The interrelationship of body is to prevent the compression of diaphragm.
● The valve can be manually/pneumatically operated, and can be controlled by control tops and solenoid valves.
◎ Size: 1"-4", DN25-DN100
◎ Pressure: 10bar (145 PSI)
◎ Material: ASTM 316L, 1.4404,1.4435 NB2 Fe <0.5%
◎ Temperature: -20 ℃ + 150 ℃ (EPDM) -4 ℉ + 302 ℉ (+ 140 ℃ (SIP, 30) 284 ℉)
◎ Connection: Clamp, Weld, Thread, 3A BPE DIN SMS IDF ISO
◎ Body Structure: straight, tee, U-tee, tank bottom valve, multi-channel diaphragm
◎ Diaphragm Material: EPDM + PTFE (double layer) / EPDM / Silicon / FPM (Viton)
◎ Certificate: 3A-54-02 / 1580, PED 97/23 EC, FDA177.2600

The manifold can be assembled by containers with various functions together. It can improve working efficiency of system and control the whole production process. The manifold can choose any flexible hose pipe and jet deviator to change the flexure automatically. The kind of automatic operation is safe, flexible and effective. One set of manifold can served to multi pipelines. Meanwhile other containers are filled in or empty, operator can clean up any one of them. The liquid won't be polluted.
Size：1.5"-DN40 to 4"-DN100
Manifold：from 4 up to 48 valves
Temperature：130℃
Pressure：10bar
Air supply：5-7bar
Control Systems
◆With a simple C-TOP on every pneumatic actuator (solenoids and sensors)
◆With a C-TOP of AS-I field bus
◆Without C-TOP, solenoids are installed in the control panel and sensors on the pneumatic actuator
◆PLC control
◆The states of the valves can be displayed on the control panel

Various Combinations Diaphragm Valve
The structures of valves have T-type,L-type, U-type, direct-way, multi-ports way, etc. It is mainly used in liquid sampling, biological systems, laboratories and other projects .
The valve is used in the pharmaceutical filling system with a particular advantage that opening and closing time can be up to 150 million life in 3 bar working pressure.
●Size: 1/4"-3/4"，DN6-DN15
●Standard: BPE 3A DIN ISO IDF
●Certificate: PED/97/23/EC，3A/54-04/1580，FDA.177.2600
●Max Temperature: -30℃ to 150℃ (Depending on seal material)(Stainless steel actuator)
●Max Temperature: -30℃ to 130℃ (Depending on seal material)(Plastic actuator)
●Max Pressure: One way (DELTA P=100%)
EPDM 8bar, PTFE 6 bar(Option)
EPDM 6bar, PTFE 4.5 bar(Option)
Double action EPDM 8 bar, PTFE 6 bar
●Assembling different actuators can meet higher pressure rating.
●Forged Body: 1.4404/316L/1.4435 BN2
●Cast Body: 1.4404/316L
●Connection: Clamp, Weld, Thread, Flange
●Operations: Manual and pneumatic

Diaphragm regulating valves are mainly used in biopharmaceutical fluid control system. The design of valve is completely empty without dead angles, liquid contact parts are high purity stainless steel and PTFE material, so it is very suitable for high purity requirements of processing piping systems. The body structure has a variety of forms and combinations (Please refer to the DONJOY diaphragm valve data).

Analog input: 0/4-20mA, 0-5/10V
Power: DC24V ± 10%
Protection: IP68 rating
Support for manual operation
One-touch auto-tuning function
Size: 1"-4", DN25-DN100
Material: 1.4435NB2, 316L, 1, .4404, ASME BPE 316L
Highest Temperature: -30 to 150 ℃ (Depending on seal material) (Stainless steel actuators)
Highest Temperature: -30 to 130 ℃ (Depending on seal material) (Plastic actuator)
Maximum Pressure: Unidirectional (DELTA P = 100%)
Normally closed rubber 8bar, PTFE 6bar (Option)
Normally closed rubber 6bar, PTFE 4.5bar (Standard)
Normally open and double acting rubber 8bar, PTFE 6bar

Manual or pneumatic operation, specifically for sanitary and aseptic processes in the pharmaceutical industry. This valve is ideal for fluid control and on/off tasks. The diaphragm provides a body seal and a seat seal. There is no path to the outside environment, so the diaphragm valve is suitable for aseptic processes. When the valve is closed, the pressure pad supporting the diaphragm moves toward the sealing surface on the valve body. As the pressure plate moves, the diaphragm bends and is forced to the seat area in the center of the valve body, thus closing the fluid path to the valve body. The relationship between the valve body and the pressure plate prevents the compression of the diaphragm. The valve can be operated manually or pneumatically, or it can be controlled by a controller and solenoid valve.
◎Specifications: 1"-4", DN25-DN100
◎ Pressure: 10bar (145 PSI)
◎Material: ASTM 316L, 1.4404, 1.4435 NB2 Fe<0.5%
◎Temperature: -20°C +150°C (EPDM)-4°F+302°F (+140°C (SIP, 30) 284°F)
◎Connection: clamp, welding, thread, 3A BPE DIN SMS IDF ISO
◎ valve body structure: straight through, three-way, U-shaped three-way, tank bottom valve, multi-channel diaphragm valve
◎ Diaphragm material: EPDM + PTFE (double layer) / EPDM / Silicon / FPM (Vitong)
◎ Certification: 3A-54-02/1580, PED 97/23 EC, FDA177.2600

In 2015, DONJOY carried out a comprehensive technical update of the check valve. After the upgrade, the check valve has a smaller dead angle, smaller flow resistance, and the valve core is sealed with full PTFE. Satisfied with automatic welding, the technology meets ASME BPE, 3-A-6800, EHEDG high clean technical requirements.
◎Check valve is designed to prevent fluid from flowing back and ensure the flow to one way direction.
◎It can be used to reduce the loss of fluid back suction,avoid pipe is shock by liquid
◎It is used in the food-processing, beverages, winery, oil, cosmetics,pharmaceuticals and chemicals industries.
◆SIZE: 1/2"-8", DN10-DN200
◆Material: 304/316L
◆ Pressure: 10bar
◆Opening pressure: 0.02bar
◆Negative pressure: -0.9bar
◆Temperature: -30 ° C to 130 ° C (150 ° C optional)
◆ valve body structure: nut type, clamp, flange
◆Interface: various special interfaces such as welding, clamp, thread, flange, etc.

Manual globe valve as pipeline switch in technology system is widely used in printing and weaving, printing and dyeing, bleaching, washing, food, chemical industry, water treatment, pharmaceutical, ect. It is featured with water hammer protection,noise-free, reliable sealing performance.

◆Size: 1/2"-3", DN10-DN80
◆Material: CF8/304、CF8M/316
◆Connection : Clamp,thread,flange,BSP、BSP、NPT、DIN
◆Working pressure：8bar(standard) 10bar(Options)
◆Working temperature：130℃(standard) 180℃(Options)

Manual non-retention ball valve is full inclusive ball seat design that solves the problem of the liquid holdup of the valve cavity. The ball valve is suitable for bio pharmaceutical engineering.
Stem seal in patent design and spring in compensation type design have advantage of long life, low torque, long-term use under high temperature 150 ℃

Size：1"-4",DN25-DN100
Material：1.4301/304,316L/1.4404
Gasket：PTFE,TFM(FDA 177.1550)
Max. temperature：-20℃ - 150℃(Standard)-30℃ - 200℃(Option)
Pressure:10-30bar(Depending on seal material and temperature)
Manual, pneumatic, electric Exchange
●Without professional tools that disassembling the valve
●Small operating torque
●Gaskets:FDA 177.2600
●Connection : Clamp, weld, thread,DIN、SMS、ISO、IDF、BPE、RJT
●No matter what the connection mode is, the valve body can be replaced, the total length without changing the valve
Certificate：3-A-68-00，PED/97/23/EC

The valve, a manual adjustment of the position and manually implement on opening and closing of reversing valve, can be used in a variety of beverages, food, cosmetics, wine and other various occasions.
●Size：DN25/1"to DN100/4"
●Temperature：130℃
●Pressure：10bar
●Air supply：4-7bar
●Material：ASTM 304/1.4301，316L/1.4404
●Gaskets：EPDM、FPM、HNBR，FDA177.2600
●Inner surface treatment：Ra<0.8μm
●Surface treatment: sandblasting, polishing
●Configuration options: position sensor, control unit
●Certificate：3-A-53-06，PED/97/23/EC,FDA177.2600

Butterfly valve whatever manual or automatic operation can be used in food processing, pharmaceutical and chemical products, industrial fluid applications.

Size: DN10-DN300, 1/2"-12"
Temperature: 130 ℃
Pressure: 10bar
Material: ASTM T304 / T316L, 1.4301 / 1.4404
Connection: Thread, Flange Welding, Clamp, etc.
Operation Standard: DIN SMS RJT 3A ISO IDF
Manual operation: Muti-handles, Pull handles
Certificate: PED / 97/23 / EC, health wading license
Pneumatic Operation: Single acting, Double acting, Triple action

◆The pump is a positive displacement lobe rotor pump designed according to USA 3A standard.
◆The equipment is processed with USA 3A to a very strict hygienic requirement.
◆The pump is suitable for transfering viscous high and low-viscous media in the food-processing,cosmetics and pharmaceutical industries.

◆ Maximum flow: 90m3 / H
◆ Maximum pressure: 20bar
◆ Maximum temperature: 150 ℃
◆ Maximum speed: 750 rpm
◆ Material: ASTM 316L, 1.4404
◆ Inside surface: Ra0.8μm
◆ Certificate: 3-A-02-11NO.1579; CE-MD / 06-42; FDA.177.2600
◆ Horizontal TUL
◆ Vertical TUR
◆ Butterfly rotor (standard)
◆ Mechanical seal: Single mechanical seal (standard) double mechanical seal (option) Material SIC / SIC, TC / TC
◆ Suitable for CIP cleaning and SIP sterilization

Twin-screw pump has self-priming ability and can transport various complex conditions such as solid particles, gas-liquid mixture, high viscosity, low viscosity and material transportation and extraction; it not only used for material extraction and Conveying, also applicable to CIP and SIP systems, can reduce pipeline, valve control, CIP dedicated pumps, Not only improve efficiency, but also reduces costs. The pump also has the performance that other volumetric pumps do not have, such as no pulse phenomenon, no damage to particles, high pressure, speed range and large flow range.
Max flow: 110m3/h
Max Particles: 23mm
Max pressure: 20 bar
Speed range: 10-3500 R.P.M
Working temperature (Max Temperature): -40 ° C to 150 ° C
Surface treatment: Ra≤0.6μm; EP=Ra0.4μm
Material: 100% stainless steel, medium contact part 316L.
Certification: 3-A-02-11 No.1759; FDA 177.2600; CE-MD/06-42 No .705201402401-00

◎Check valve is designed to prevent fluid from flowing back and ensure the flow to one way direction.
◎It can be used to reduce the loss of fluid back suction,avoid pipe is shock by liquid
◎It is used in the food-processing, beverages, winery, oil, cosmetics,pharmaceuticals and chemicals industries.
◎The valve is open when pressure of the fluid exceeds the spring pressure and it is closed when the two pressures are close equal.And stronger counter-pressure also makes the valve closed.

◎Specifications: DN-50/2" TO DN-300/12"
◎Boby/shaft: AISI 316L/304
◎Spring: AISI 304
◎Seal: EPDM according to FDA177.2600
◎Surface Treatment: Ra ≤0.8 μm
◎Seal: NBR, FPM (Viton) or PTFE. FDA 177.2600(optional)
◎Connections: weld, thread, clamp, DIN, SMS, RJT, IDF, ISO,3A
◎Max. pressure：10 bar
◎Opening pressure：0.3bar(DN-25)0.2bar(DN-32/40)0.1bar(DN-50/100)
◎Working temperature ： -10℃ to 130℃(EPDM)

Pneumatic Globe Valve as an automatic control system of line switch is widely used in printing and weaving, printing and dyeing, bleaching, washing, food, chemical industry, water treatment, pharmaceutical, ect. It has the characteristics of anti water hammer, no noise, reliable sealing performance etc..

◆Size: 1/2"-3", DN10-DN80
◆Material: CF8/304、CF8M/316
◆Connection : Clamp,thread, flange,BSP、BSP、NPT、DIN
◆Working pressure：8bar(standard) 10bar(Options)
◆Working temperature：120℃(standard) 180℃(Options)
◆Manual：1) plastic handwheel; 2) stainless steel handwheel; 3) fine-tuning the handwheel
◆Pneumatic：1) plastic actuator (standard) 2) stainless steel actuators (option)
◆Pneumatic control mode: positioner, process controller, valve control unit, position sensor

Horizontal pneumatic non-retention ball valve is full inclusive ball seat design that solves the problem of the liquid holdup of the valve cavity. The ball valve is suitable for bio pharmaceutical engineering.
Stem seal in patent design and spring in compensation type design have advantage of long life, low torque, long-term use under high temperature 150 ℃

Size： 1/2"-4",DN10-DN100
Temperature：-30℃ - 150℃
pressure：10bar
Material：304/1.4301,316L/1.4404
Surface：Ra≤0.5μm
Gasket:FDA 177.1550
Connection : Clamp, weld, thread，DIN，SMS，ISO，IDF，BPE，RJT
Electric Actuator
Function: switch type, adjustment type, passive contact
Power supply: DC 24V AC 110V 220V
The opening and closing time: 10/S-100/S
Torque: 6N.M to 2000N.M
Protection: IP67 grade
Explosion-proof: EX DII BT4 (option)

he reversing valve seat is a sanitary single seat pneumatic operation valve. In the food processing industry, beverage production of pharmaceutical and fine chemical industry, it has a wide range of applications.

● Size: DN25 / 1 "to DN100 / 4"
● Temperature: 130 ℃
● Pressure: 10bar
● Air supply: 4-7bar
● Material: ASTM 304 / 1.4301,316L / 1.4404
● Seal: EPDM, FPM, HNBR, FDA177.2600
● inner surface treatment: Ra <0.8μm
● Surface treatment: sandblasting, polishing
● Certificate: 3-A-53-06, PED / 97/23 / EC, FDA177.2600

Butterfly valve whatever manual or automatic operation can be used in food processing, pharmaceutical and chemical products, industrial fluid applications.

Size: 1/2"- 12", DN10-DN300
Material: 304 / 316L, 1.4301 / 1.4404
Pressure: 10bar
Temperature: 130 ℃
Connection: weld, thread, clamp, three flange
Operation Standard: DIN SMS ISO IDF RJT DS

Rotary pump with heat jacket , there are three jacket designs: periphery heat jacket,surface heat jacket and complete heat jacket. It is suitable for high viscosity fluid, such as chocolate,syrup, candy and etc. It will avoid freezing, deterioration caused by temperature deference.
◆ Maximum flow: 90m3 / H
◆ Maximum pressure: 20bar
◆ Maximum temperature: 150 ℃
◆ Maximum speed: 750 rpm
◆ Material: ASTM 316L, 1.4404
◆ Inside surface: Ra0.8μm
◆ Certificate: 3-A-02-11NO.1579; CE-MD / 06-42; FDA.177.2600
◆ Horizontal TUL
◆ Vertical TUR
◆ Butterfly rotor (standard)
◆ Mechanical seal: Single mechanical seal (standard) double mechanical seal (option) Material SIC / SIC, TC / TC
◆ Suitable for CIP cleaning and SIP sterilization

◎Check valve is designed to prevent fluid from flowing back and ensure the flow to one way direction.
◎It can be used to reduce the loss of fluid back suction,avoid pipe is shock by liquid
◎It is used in the food-processing, beverages, winery, oil, cosmetics,pharmaceuticals and chemicals industries.
◎The valve opens when pressure of the fluid exceeds the spring pressure.It is closed when the two pressures are close equal.And stronger counter-pressure also makes the valve closed.

◎Specifications: DN-25/1" TO DN-100/4"
◎Boby/shaft: AISI 316L/304
◎Spring: AISI 304
◎Seal: EPDM according to FDA177.2600
◎Surface Treatment: Ra ≤0.8 μm
◎Seal:NBR, FPM (Viton) or PTFE. FDA 177.2600(optional)
◎Connections: weld, thread, clamp, DIN, SMS, RJT, IDF, ISO,3A
◎Max. pressure：10 bar
◎Opening pressure：0.3bar(DN-25)0.2bar(DN-32/40)0.1bar(DN-50/100)
◎Working temperature ： -10℃ to 130℃(EPDM)

Straight Ball valve both manually and automatically operated valve are mainly used in processing beverages, wine, oil refining, cosmetics and chemical industries.

●Size：1/2"-4",DN10-DN100
●Temperature：-20℃ - 120℃
●Pressure：10-bar
●Material：AISI 304 316L
●Smaller and lighter than the other valve
●Operating torque is small
●Gaskets:PTFE FDA 177.1550
●Whatever the connection is, it does not change the total length of the valve
●Connection : Clamp, weld, thread, Flange, DIN、SMS、RJT、FIL
●Can be equipped with pneumatic actuators, electric actuators
●Material contact parts:AISI，304/316L
●Certificate：PED/97/23/EC

Diaphragm type pneumatic reverse valve with all functions of standard reversing globe valves. It bears stand high pressure valves in shorter height, fights severe water hammer and install side mounted positioner for automatic flow control.
●Size：DN25/1"to DN100/4"
●Temperature：130℃
●Pressure：10bar
●Air supply：4-7bar
●Material：ASTM 304/1.4301，316L/1.4404
●Gaskets：EPDM、FPM、HNBR，FDA177.2600
●Inner surface treatment：Ra<0.8μm
●Surface treatment: sandblasting, polishing
●Configuration options: Position Sensor
●Certificate：3-A-53-06，PED/97/23/EC,FDA177.2600

Pneumatic Butterfly Valve both manual and automatic operation, can be used in industrial applications in fluid products, such as food processing, pharmaceutical and chemical industries.
Size: DN10-DN300, 1/2"-12"
Temperature: 130 ℃
Pressure: 10bar
Material: ASTM T304 / T316L, 1.4301 / 1.4404
Connection: Thread, Flange, Weld, Clamp
Operation Standard: DIN SMS RJT 3A ISO IDF
Pneumatic operation: Single acting, Double acting, Three action
Certificate: PED / 97/23 / EC, health wading license

Three-way diaphragm valves, manually or pneumatically operated, it is specifically designed for hygienic and aseptic processes in the pharmaceutical industries.
◎ Size: 1"-4", DN25-DN100
◎ Pressure: 10bar (145 PSI)
◎ Material: ASTM 316L, 1.4404,1.4435 NB2 Fe <0.5%
◎ Temperature: -20 ℃ + 150 ℃
◎ Connection: Clamp, Weld, Thread, 3A BPE DIN SMS IDF ISO
◎ Body structure: U type tee + sampling valve; U-type links
◎ Diaphragm material: EPDM + PTFE (double layer) / EPDM / Silicon / FPM (Viton)
◎ Certificate: 3A-54-02 / 1580, PED 97/23 EC, FDA177.2600
